SCP 111 S-DIAS SAFETY CPU MODULE
Page 26 04.11.2020
6.1.4 Error Sequence
If an invalid button press occurs, as in the sequences described above, the Error sequence
is initiated. LED B indicates this sequence with fast blinking, which lasts for at least 3 seconds.
If the button is still pressed after 3 seconds, LED B will continue to blink until the button is
released and a minimum pause of approximately 200 ms has elapsed. The Start sequence
cannot be reinitiated until LED B stops blinking.
After ending the Error sequence, the mode is changed as described in "Overview of Module
Statuses". If turned on, LEDs C1, C2 and C3 are turned off after ending the Error sequence.
