SIGMATEK SCP 111 User Manual

S-DIAS SAFETY CPU MODULE SCP 111
04.11.2020 Page 41
12.2 Safety
Safety State
State
Status of the Safety module.
Possible Statuses and their meaning:
_ModuleNotFound
The module was not found at the set position.
_SafetyClassOK
The module was located and initialized
without error.
_MemAllocFailed
An attempt to allocate memory for the module
has failed.
_ReadFWVerFailed
The module's firmware could not be read.
_ReinitConfig
The configuration in the CPU has changed
and the hardware classes are now being
updated.
_ModFromCfgNotFound
A module from the configuration is not
physically available, its hardware class has
been placed however.
A module from the configuration is not
physically available and its hardware class
has not been placed.
A module from the configuration is not a C-
DIAS module (according to its HW path).
_UnsafeVarNotFound
An unsafe variable cannot be found in the
project. Compare the syntax in the
SafetyDesigner and the project.
_UnknownCfgError
An error has occurred while reading the
configuration or when creating the routing
tables.
_AsyncComError
Several sequential asynchronous
commands failed. Please contact
SIGMATEK support
_DOsIncreasedRestartAp
p
The number or sized of the module access
was increased with a new Safety project. =>
The application must be restarted, because
the new data is not covered by the current
access.
_LostPowerSupply
The CPU supply has failed.
_WrongSafetyHW
The placed Safety modules in the project do
not match the actual modules.
For each physical module, a Safety object
must be placed in the project.
Run State
State
Shows whether the module is in operational mode.
0
Operational mode inactive
1
Operational or temporary operational mode active
Service Mode
State
Shows the operating status of the module.
0
Operational mode
1
Service mode
2
"Check Configuration"-Phase active
