SIGMATEK SCP 111 User Manual

SCP 111 S-DIAS SAFETY CPU MODULE
Page 14 04.11.2020
3 Technical Data
3.1 Performance Data
Interfaces
1x Safety Interface
Program interfaces
1x USB device
Bus connection possible
yes
Miscellaneous
microSD slot
Supply voltage
+24 V
3.2 Electrical Requirements
3.2.1 Module Supply (Input)
Supply voltage
+18-30
(5)
V DC, typically +24 V DC
UL: Class 2 or LVLC
(1)
Current, internal consumption
typically 90 mA internal consumption
maximum 1.4 A
(2) (3)
Current consumption
from the S-DIAS bus
+5 V
+24 V
with missing
+24 V connection (X3)
typically
170 mA
maximu
m
200 mA
0 A
0 A
with existing
+24 V connection (X3)
0 A
0 A
0 A
0 A
A fuse for the supply voltage must be installed, which can sufficiently limit voltage
and current.
Un fusible conforme aux limites de la tension et du courant d'alimentation doit être
présent en amont de l'alimentation.
