2.4 LabScat 2 technical data
DATA
VALUES
Measuring principle
Scattered light measurement 90°/25°
Measurement span
0 .. 200 EBC (optional: 0 .. 500 EBC)
Color depth of the
sample
Depending on bottle color and bottle diameter
Measuring time
12 seconds
Wavelength
650 nm according to MEBAK recommendation
Radiation class
LED device of Class 1 according to EN 60825-1
Measuring angle
90° and 25°
Resolution
< ± 1% of the measuring value or ± 1 mEBC
Reproducibility
0 .. 2 EBC: ± 1% or ± 1 mEBC of the measuring value
2 .. 200 EBC: at 90° ±2%, at 25° ±3% of the measuring value
Repeatability
0.001 EBC or ±0.1% full scale
Supply voltage
12 VDC with separate power unit
Power consumption
10 W
Interfaces
Ethernet, USB, Modbus TCP, optional Modbus RTU/Profibus DP
Reading
¼ VGA with touchscreen
Resolution: 320 x 240 pixel, 3.5” diagonal
Water bath connec-
tions
Circulation approx. 0.5 l/min., max. Pressure 0.6 MPa (6 bar)
Warm-up time
Less than 5 min.
Bottle dimensions
Ø 50 to 88 mm, height up to 330 mm
Ambient temperature
0 .. +40 °C
Ambient humidity
0 .. 99% relative humidity
Weight
5 kg
Dimension
L: 282.5 mm (343 mm when cover open)
H: 393 (480 mm when cover open)
W: 185.5 mm
