SIGRIST LabScat 2 User Manual

Operation Instruction Manual LabScat 2
12112E/2 29
7.7 Copy measurement data to USB stick
Only the data that was added since the last time data was transferred will be copied.
WORKSTEP
ADDITIONAL INFO / IMAGES
1.
Ensure the instrument is in normal operation.
2.
Remove splash guard from the USB port.
3.
Insert USB memory stick into the port.
4.
After the USB memory stick is inserted, the
saved measuring values are automatically cop-
ied to the USB memory stick.
Status of the USB display:
 During copying, the USB display is green.
 After saving is completed, the USB display
changes to blue.
 The USB display changes to red if no
measuring values are saved or if an error
occurs during the data transfer.
5.
Remove USB memory stick and insert splash
guard in the USB port.

SIGRIST LabScat 2 Specifications

General

Brand	SIGRIST
Model	LabScat 2
Category	Measuring Instruments
Language	English
