1. Overview
1 Filter for double espresso
2 Filter for single espresso
3 Hot plate for cups
4 OFF / Dial for steam and hot water production
5 Lid (of the water tank)
6 Water tank (filling volume: 250 ml - MAX 1,000 ml)
7 Power cable with mains plug
8 On/off switch
9 Tamper
10 Steam nozzle
11 Float (indicator: empty drip tray)
12 Drip tray
13 Drip grid
14 Brewing head
15 Control elements (front panel)
16 Portafilter
Figure A: control elements (front panel)*
17 Button/LED ring for single espresso
18 Button/LED ring for double espresso
19 Button/LED ring for steam production
* The control elements have other functions that are explained in these user instructions.
Figure B: filter and portafilter
20 Notch in the edge of the filter1/2
21 Nub on the side of the filter1/2
22 Notch in the edge of the portafilter16
no image: 1 bottle descaling agent (approx. 125 ml)
