SIMARINE PICO User Manual

EN
2. Accessories
10
Accessories
2.
2. Accessories
PICO is compatible with the following SIMARINE modules:
· SC303 Digital Shunt – 300A Shunt, for up to 75V systems.
· SC503 Digital Shunt – 500A Shunt, for up to 75V systems.
· SDI01 Inclinometer – High-resolution digital inclinometer for pitch and roll with manual calibration.
· SCQ25 Quadro Digital Shunt Module – 4x25A Shunt, for 12V and 24V systems
· SCQ50 Quadro Digital Shunt Module – 4x50A Shunt, for 12V and 24V systems.
· SCQ25T Quadro Digital Shunt and Analog input module 4x25A Shunt and Analog input module with 4 resistance and 3
voltage inputs.
· ST107 Analog input interface module with 4 resistance and 3 voltage Inputs.

SIMARINE PICO Specifications

General

Connectivity	Wi-Fi, Bluetooth
Power Supply	12-24V DC
Water Resistance	IP67
Dimensions	83 x 76 x 10 mm
Flush Mount Depth	8 mm
Display	LCD
Operating Temperature	-20°C to 70°C
