EN
7. Screens
40
Screens
7.
7.3
Temperatures screen
Temperatures screen shows current temperatures of connected and correctly configured temperature sensors.
Up to four temperature sensors can be shown on a single screen.
If there are more, they divide into two or more screens.
For each sensor, you can find its name, graphical representation of the current temperature, and the numerical value of the
current temperature in the chosen unit (°C or °F).
If the temperature sensor is not selected in the temperature sensor settings or the sensor is disconnected from the PICO
system, the “OFFLINE” symbol will appear. If this situation occurs, please check the temperature sensor setting. If a device is
selected, please check if all the cables are properly connected.
NOTE: In case your temperature is displayed as a constant -13°C (8.2°F) or some other high or low value, then the
most likely problem is that you do not have a correct sensor input selected. Selecting any sensor input to which no
temperature sensor is connected to, will result in such readings.
