7. Screens
42
Screens
7.
7.5
Inclinometers screen
If you have an inclinometer installed, the “Inclinometers screen” shows your pitch and roll data.
Pitch is shown on the left side of the screen. The left side of the line represents the front of the vehicle or boat (bow), while
the right side of the line represents the back of the vehicle or boat (stern).
The pitch angle in degrees is shown below the line (positive value meaning front facing up and vice versa).
Roll is shown on the right side of the screen. The left side of the line represents the left-hand side of the vehicle or boat. The
roll angle in degrees is shown below the line (positive value meaning left-hand side up and vice versa).
