6. Basic Setup
33
Basic Setup
6.
6.9.1 Adding a new user sensor
In the settings menu, navigate to DEVICES > USER SENSORS.
Select “Add newand fill in the requested data.
·
NAME Name the user sensor.
·
VOLTMETER Select the voltage input used to measure the analog output of your voltage type user sensor.
·
LOW VALUE POINT – What value is presented by the LOW VOLTAGE POINT (see bellow).
·
HIGH VALUE POINT What value is presented by the HIGH VOLTAGE POINT (see bellow).
·
RANGE (MIN/MAX) Select the minimum and maximum point displayed on the graph of the user sensor.
·
DECIMALS Set an offset of the decimal point (from right to left).
·
MEASUREMENT UNIT Input the measurement unit that will be presented on the display graph.
·
LOW VOLTAGE POINT – Expected voltage when the sensor measures its lowest value.
·
HIGH VOLTAGE POINT – Expected voltage when the sensor measures its highest value.
·
DELETE - With this option, you can delete the selected user sensor.
6.10
Current sensors configuration
6.10.1 Current sensors
List of all current sensors (shunts). Connected shunt modules are added to the list automatically. In this list, you can view
real time readings (amperes) for all connected current sensors. By selecting a certain sensor, you can view or change its
settings.
