6. Basic Setup
30
Basic Setup
6.
·
CAPACITY – Input the full tank capacity.
·
CALIBRATION POINTS – Add calibration points for different tank levels. For a proper configuration at least two
calibration points are required.
For square shaped tanks we suggest two calibration points (full and empty).
For irregular shaped tanks, we suggest you input a third (the middle) point. The rest will be calculated by PICO on the fly.
·
DISPLAY PRIORITY – Set the display priority of the tank (this is practical only when there are multiple tanks configured)
·
DISPLAY MODE
- Standard – displays tank content in measuring unit and percentage.
- Fewer data - display tank content only in percentage
·
INSTANCE – An identifier for NMEA2000 network. For use with NMEA2000 each tank has to have a unique instance
field. Confirm and save the tank configuration with button.
The newly added tank should now be visible on one of the PICO’s screens, once you exit the settings menu (visible on the
main menu screen).
COMPATIBLE TANK SENSORS:
Any analog voltage/resistance type tank sensor, that is made for general use and not locked to a specific tank level monitor,
will work with the SIMARINE system.
The compatible ranges are:
Resistance: 0 Ohm - 65000 Ohm (65kOhm) or anything in between.
Voltage: 0.0V - 70.0V or anything in between.
