DL100 Series Universal Low-Power Inverter
Function Parabeter Table 23
F2.04
V/F voltage 1
0~[F2.01]
1
0
F2.05
V/F frequency 2
0.00~[F2.00]
0.01
0.00
F2.06
V/F voltage 2
0~[F2.01]
1
0
F2.07
V/F frequency 3
0.00~[F2.00]
0.01
0.00
F2.08
V/F voltage 3
0~[F2.01]
1
0
F2.09
Reserve
F2.10
Zero frequency
torque hold
0: invalid 1: valid
0
0
F2.11
Automatic
voltage
stabilization
0: Invalid
1: Invalid
deceleration
2: Effective
1
0
F2.12
Number of
motor pole pairs
1~16
1
2
F2.13
Reserve
F2.14
Reserve
F2.15
Reserve
F2.16
UP/DW terminal
rate
0.10~10.00
0.01
1.00
F2.17
Reserve
F2.18
Reserve
F2.19
Reserve
Digital input and analog parameter group
F3.00
Input terminal
characteristics
selection
0000~1111
1
0000
F3.01
Multi-function
terminal X1
0~21
1
11
F3.02
Multi-function
terminal X2
0~21
1
0
F3.03
Multi-function
terminal X3
0~21
1
13
F3.04
Multi-function
terminal X4
0~21
1
0
F3.05
Reserve
F3.06
Reserve
F3.07
Reserve
F3.08
Reserve
F3.09
AI input lower
limit voltage
0.00~[F3.10]
0.01
0.00
F3.10
AI input upper
limit voltage
[F3.19]~10.00
0.01
10.00
F3.11
AI input filter
time
0~200
1
10
F3.12
Minimum set
frequency
0.00~[F3.13]
0.01
0.00
F3.13
Maximum set
frequency
[F3.12]~[F0.03]
0.01
50.00
F3.14
Reserve
