DL100 Series Universal Low-Power Inverter
22 Function Parabeter Table
Basic control parameter group
F1.00
Start
pre-excitation
voltage
0.0~20.0%
0.1
2.0
F1.01
Start
pre-excitation
time
0.00~10.00
0.01
0.0
F1.02
Start frequency
0.00~min
(F0.03,100.0)
0.01
1.00
F1.03
Start frequency
hold time
0.00~10.00
0.01
0.0
F1.04
Stop mode
0~1
1
0
F1.05
DC braking
frequency at
stop
0.0~min
(F0.03,100.0)
0.01
5.00
F1.06
DC braking
voltage at stop
0.0~20.0%
0.1
3.0
F1.07
DC braking time
at stop
0.00~20.00
0.01
0.00
F1.08
Energy
consumption
braking level
340~400/650~800
1
360/680
F1.09
Dynamic
braking action
selection
0~1
1
0
F1.10
Inhibition of
action selection
0000~1111
1
0000
F1.11
Undervoltage
suppression
level
160~220/340~420
1
190/380
F1.12
Overvoltage
suppression
level
350~400/650~800
1
360/700
F1.13
Accelerating
current limit
level
120~220
1
180
F1.14
Operating
current limit
level
120~220
1
200
F1.15
Reserve
F1.16
Motor overload
protection level
10~130%
1
110
F1.17
Reserve
1
F1.18
Failure
self-recovery
times
0~5
1
0
F1.19
Fault
self-recovery
time
0.00~600.00
0.01
1.00
电
机
Parameter
group
F2.00
Fundamental
frequency
5.00~600.00
0.01
50.00
F2.01
Maximum
output voltage
25 ~250V/50 ~ 500V
1
220/380
F2.02
Torque boost
0.0~20.0%
0.1
3.0
F2.03
V/F frequency 1
0.00~[F2.00]
0.01
0.00
