DL100 Series Universal Low-Power Inverter
Detailed Description of Functions 33
Set
value
Combination method
Set
value
Combination settings
0
External voltage setting + panel
setting
1
External voltage setting + panel
setting + digital setting
2
Communication setting +
external voltage setting
3
Communication setting +
external voltage setting + panel
setting
4
Communication setting-panel
setting + digital setting
5
Communication setting-external
voltage setting
6
Serial port setting + external
voltage setting-panel setting
7
External voltage setting-panel
setting + digital setting
8
Panel Setting-Digital Setting
9
UP/DW frequency + external
voltage setting
10
UP/DW frequency + panel
setting + external voltage
setting
11
Digital setting-external voltage
setting
Define the rate at which the output frequency of the inverter changes up and
down.
Acceleration time The time required for the output frequency to accelerate
from 0.00Hz to the upper limit frequency [F0.03].
Deceleration time The time required for the output frequency to decelerate
from the upper limit frequency [F0.03] to 0.00Hz.
The transition acceleration and deceleration time between the initial running
frequency and the jog frequency.
F0.14 acceleration time Predetermined area ： 0.01 ~ 600.00Sec
F0.15 deceleration time Predetermined area ： 0.01 ~ 600.00Sec
F0.18 Forward jog frequency Predetermined area ： 0.00Hz ~[F0.03]
F0.19 Reverse jog frequency Predetermined area ： 0.00Hz~[F0.03]
F0.16 Jog acceleration time Predetermined area ： 0.01 ~600.00Sec
F0.17 Jog deceleration time Predetermined area ： 0.01 ~600.00Sec
