Simplex 4100U User Manual

3-7
3. Press the <ENTER> key. The alphanumeric display shows the action taken.
Note: The system indicates a trouble condition each time a point is disabled. It is
important to repair the disabled point as soon as possible. Once repaired, the
disabled point should be enabled as soon as possible. See “Enabling a Disabled
Point” for additional information.
If the Trouble Doesn’t Clear, Continued
Disabling a Point
with a Trouble
Condition,
(continued)
ACTION TAKEN
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
