Simplex 4100U User Manual

4-4
2. Press the SUPV ACK key. Repeat this step and read the reports. The alphanumeric display
shows the area and type of condition. The tone-alert silences and the yellow LED glows
steady.
a. The tone-alert silences and the LED glows steady.
b. The display shows the area and type of problem, as shown below.
OR
3. Read the alphanumeric display. Investigate the problem to determine its cause. Restore or
replace the defective device (switch, wire, notification appliance) in accordance with the
manufacturer’s instructions, or call Simplex to repair the system.
When the problem causing the condition is corrected, the SUPERVISORY LED flashes and
the tone-alert sounds steady.
4. Press the SUPV ACK key. The display shows the system status.
5. Press the SUPV ACK key again. After a short delay, the display indicates that the system is
normal.
Acknowledging Supervisory Conditions, Continued
Individually
Acknowledging
Supervisory
Conditions,
(continued)
FIRST FLOOR EAST WING ROOM 31
Press <ACK> key to acknowledge
FIRST FLOOR EAST WING ROOM 31
FIRE PUMP MONITOR RUNNING
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
