Simplex 4100U User Manual

viii
Resetting the Audio System .................................................................................... 8-6
Two Channel Audio Operation .................................................................................... 8-7
Overview.................................................................................................................. 8-7
Evacuate Entire Building.......................................................................................... 8-8
Evacuate Specific Floors when No Alarms are Present.......................................... 8-8
Evacuate Additional Floors During an Alarm........................................................... 8-8
Alert Specific Floors................................................................................................. 8-8
Evacuate Floors On Which Alert Message is Playing ............................................. 8-9
Page Entire Building ................................................................................................ 8-9
Page Specific Floors................................................................................................ 8-9
Page Additional Floors............................................................................................. 8-9
Listen to What is Being Played on the EVAC Channel Using the Local Speaker... 8-9
Listen to What is Being Played on the Alert Channel Using the Local Speaker ... 8-10
Silencing the Audio System................................................................................... 8-10
Resetting the Audio System .................................................................................. 8-10
Three to Eight Channel Audio System Operation ..................................................... 8-11
Overview................................................................................................................ 8-11
Evacuate Entire Building........................................................................................ 8-12
Evacuate Specific Floors when No Alarms are Present........................................ 8-12
Evacuate Additional Floors During an Alarm......................................................... 8-12
Alert Specific Floors............................................................................................... 8-12
Evacuate Floors On Which Alert Message is Playing ........................................... 8-13
Page Entire Building .............................................................................................. 8-13
Page Specific Floors.............................................................................................. 8-13
Page Additional Floors........................................................................................... 8-13
Play Announcements on Specific Floors............................................................... 8-14
Listen to What is Being Played on the EVAC Channel Using the Local Speaker. 8-14
Listen to What is Being Played on the Alert Channel Using the Local Speaker ... 8-14
Silencing the Audio System................................................................................... 8-14
Resetting the Audio System .................................................................................. 8-14
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
