Simplicity LTH Series

7 Transmission Repair
7C Tuff Torq K60
7 - 54
18. Remove the spring and retaining ring from the input
shaft.
21. Remove the two shift blocks from the control shaft.
22. Inspect the shift blocks for wear or damage. Replace
if necessary.
Figure C–34 Remove Shift Blocks
19. Remove the swash plate assembly.
20. Inspect swash plate assembly for wear or damage.
Replace if required.
Figure C–32. Remove Pump Spring
Figure C–33. Remove Swash Plate
