CR44/54 Miscellaneous menu Chapter 7-13
7.7.1 Satellites in SDGPS system
The SDGPS system consist of eight orbiting geostationary satellites.
It is, however, not expected to become fully employed till sometime
in 2003. In the meantime, the system will have limited usage but will
be available to all users with the latest Simrad equipment, such as
the CRXX ChartRadar.
Number Name System Area
120
AOR-E EGNOS - EU
Atlantic ocean region east
122
AOR-W WAAS - US
Atlantic ocean region west
124
ARTEMIS EGNOS - EU
126
INMARSAT EGNOS - EU
129
MTSAT-1 MSAS - JAPAN
131
IOR EGNOS - EU
Indian ocean region
134
POR WAAS - US
Pacific ocean region
137
MTSAT-2 MSAS - JAPAN
Tracking state
The letter indicating the tracking state will appear immediately after
the satellite number in the display.
Letter indication: - means that the receiver is:
S searching for satellite.
D trying to synchronize to data stream.
C code locked to signal.
P phase locked to signal.
