Chapter 3-20 CR44/54 Radar menu
3.2.6 Radar quick menu
From active radar display:
ENT
Call up the Radar quick menu
Radar quick menu
1
Activate EBL1/VRM1
2
Activate EBL2/VRM2
3
Show Cursor
4
Show active navigation point
7
Heading line
8
Clear trails
GOTO
Transmit
RADAR
Power on
MENU
Exit
If working with both EBL/VRM cursors, you can toggle between
which one should be active via the quick menu.
1
Activate EBL1/VRM1
A dotted line + circle will be drawn on the screen. Use the cursor
key to move the EBL1/VRM1 cursor. By placing the dashed circle
over a target or over an object, it will indicate the distance to same.
To turn off: Press [ENT], [1] again to hide EBL1/VRM1.
Long press on [CLR] will turn off all active cursors.
Toggle on/off directly from the [EBL] key.
2
Activate EBL2/VRM2
A dotted line + circle will be drawn on the screen. Use the cursor
key to move the EBL2/VRM2 cursor. By placing the dashed circle
over a target or over an object, it will indicate the distance to same.
To turn off: Press [ENT], [2] again to hide EBL2/VRM2.
Long press on [CLR] will turn off all active cursors.
3
Show cursor - will activate cursor on radar display. Press again to
hide cursor, or press [CLR]. Long press on [CLR] will turn off all
active cursors on the radar display.
