Chapter 9-6 CR44/54 Setup menu
TL50 version - indicates if a TL50 Turbo Loader is connected and
which software version is implemented.
GPS receiver type - indicates which type is installed in the unit (for
technicians only).
PAGE rotat ion inter val - can be set to anywhere between 03 to 99
seconds. Refer to “Fundamentals of the display and page system” in
section 2.1 for more details on how the function works.
Display text in - as standard the CRXX is supplied with the follow-
ing national display languages: Danish (DK), English (GB), English
(US), French (F), German (D), Italian (I), Nederlands (NL), Spanish
(E), Swedish (S), and Portuguese (P).
9.4 Interface setup, NMEA
The CRXX has two in/out ports:
1. NMEA1 contains both an NMEA port and the connection for the
dual station. The NMEA1 data from the main unit is available
from NMEA2 port on the dual station.
2. NMEA2 is recommended for standard NMEA interfacing.
The two NMEA ports can be set individually to:
NMEA0183
EXT. DGPS (external DGPS)
NMEA0180
NMEA0182
The next pages indicate the default settings for the interface setups.
After the interface setups will follow a description of the input and
output sentences available in the setups - see sections 9.4.1 and 9.4.2.
MENU
Call up the menu bar, and...
7, 2
load NMEA interface
+/-
Toggle between INPUT and OUTPUT
Go to, and...
To Next Page
