CR44/54 Radar menu Chapter 3-13
press [CLR].
4. Set ‘Tune’ bar to ‘AUTO’ mode: move cursor to the ‘Tune’ bar and
press [CLR].
5. Choose a displayed range of 0.5nm (press key [7]).
Now you are ready to adjust the Auto sea values in the lower part
of the Radar setup display (example shows default settings for
RB715A):
Auto sea minimum
(factory value 055): Adjust to visible Sea clutter
on screen.*
Auto sea default
(factory value 070): Adjust to best picture.*
Auto sea maximum
(factory value 160): Adjust to max. allowable
suppression of sea clutter.* (If the value is set too high, some targets
may be invisible on close range).
*) wait for screen to update to see the result of adjustment.
Auto Sea clutter adjustment bar (example)
Level: 055 070 160
Test scanner – to activate press one of the +/- keys, which will call
up an info window. Press [CLR] to initiate a test of the scanner,
which will provide measurement values and other technical details.
(For technicians only).
3.2.3 Start transmission
Normally, when starting the transmission, it will take approx. two
minutes for the antenna to warm up and be ready for transmission.
For initial start-up and after long storage, see below.
Make sure nobody is standing close to the radar antenna when it
starts to rotate after the transmission is activated!
RADAR
Shortcut to radar display
ENT
Call up the Radar quick menu
RADAR
Turn ‘Power on’
AUTO
