Chapter 3-10 CR44/54 Radar menu
Example of Radar setup:
HU
0.50nm
Head-Up, North-Up, True Motion
Range= 0.50nm
Power off
Power off, X-MIT
TI 0
Tuni ng I ndicator
Tune 0
*Tune, Gain, Sea: adjust with +/- keys, and press
[CLR] to return to AUTOmatic mode.
Gain 0
Sea 0
Rain 0
*Rain Clutter / FTC
Scanner type Auto detect
/Demo/
RB714A/RB715A/RB716A/RB717A/RB718A
Antenna height 05m
5 meters above water
Heading adjust 000.0°
*In degrees to 0°
Tuning reference 079
*Adjust with +/-/numeric keys
Zero range/timing 0109
*Adjust with +/-/numeric keys
Sensitivity 048
*Adjust with +/-/numeric keys
GZ target threshold 5
*Levels of 1 to 7
Stand-by time 000000 h
Elapsed stand-by time
Transmit time 000000 h
Elapsed transmission time
Auto sea minimum 035
*Auto sea and Auto gain are preset for best per-
formance under normal conditions.
*= only adjustable in X-MIT mode.
More details on next pages.
Auto sea default 050
Auto sea maximum 070
Auto gain minimum 080
Auto gain default 090
Auto gain maximum 105
Test scanner Activate
For technicians only.
Use the cursor key to move around in the settings. Toggle between
available values with the +/- keys, and insert data by the numeric
keys.
ENT
Confirm the adjustments by [ENT] or [MENU]
Scanner type: is preset to Auto detect. After having installed the
scanner (see the Installation manual for selection of scanner), the
system will automatically set up the correct parameters for the con-
nected scanner. However, if the Auto detection fails, you could try to
manually set up the connected scanner. The radar function must stay
AUTO
AUTO
AUTO
To Next Page
