Chapter 3-22 CR44/54 Radar menu
the window must be active:
WIN
Toggle between active windows on screen
ADJ
Open for adjustment
- by pressing [ADJ] again will toggle between 1st and 2nd half of
control menu.
Use the cursor to move around in the control menu
- and toggle between available values with the +/- keys, and insert
data by the numeric keys.
ENT
Confirm changes by pressing [ENT] or [MENU]
To make adjustments in the secondary radar display:
WIN
Make the secondary radar display active
Carry out adjustments by using the same procedures as mentioned
above for the standard radar display, except for the guard zone which
is not available in the secondary radar display.
Indication of HDG (heading) and Rpm (scanner rotation speed) is
only available in full screen presentation.
