Simrad GO XSE Installation Manual

3 Sonar - CHIRP, Broadband, DownScan, and SideScan
imaging (dependent on the transducer)
4 Card reader
GO9-XSE rear connections
1
2
3
4
5
RADAR NMEA2000 POWER SONAR
1 Radar - radar (Ethernet) connection
2 NMEA 2000 - data input / output
3 Power - 12 V DC supply input
4 Sonar - CHIRP, Broadband, DownScan, and SideScan
imaging (dependent on the transducer)
5 Card reader - dual slot
Card reader
Used for attaching a microSD memory card. The memory card can
be used for detailed chart data, software updates, transfer of user
data, and system backup.
The card reader door is opened by pulling the rubber cover open.
The card reader door should always be securely shut immediately
after inserting or removing a card, in order to prevent possible water
ingress.
Overview | GO XSE Installation Manual
15
