Simrad GO XSE - GO9 XSE Dimensional Drawings

GO9 XSE Dimensional drawings
242.0 mm (9.52”)
248.0 mm (9.76”)
263.0 mm (10.35”)
24.0
mm
(0.94”)
184.0 mm (7.24”) 170.0 mm (6.69”)
7.0 mm (0.27”)
90.0 mm (3.54”)
79.0 mm (3.11”)
