Simrad GO XSE Installation Manual

Contents
11 Check the contents
11
GO5 XSE box contents
12 GO7 XSE and GO9 XSE box contents
13 Overview
13 Front controls
14 Rear connections
15 Card reader
17 Installation
17 Mounting location
18 Bracket mounting
20 Panel mounting
21 Transducer installation
22 Wiring
22 Guidelines
23 Power Connections
24 Power Control connection
25 External alarm
26 Connecting control devices
26 NMEA 2000 backbone
28 CZone connection to NMEA 2000
29 Transducer connection
29 Radar connector
31 Software Setup
31 First time startup
31 Time and Date
31 Data source selection
33 Device list
34 Sonar setup
35 StructureScan
35 Radar setup
40 Autopilot setup
52 Fuel setup
55 CZone setup
57 Wireless setup
Contents | GO XSE Installation Manual
9

Simrad GO XSE Specifications

General

GPS	Yes
Chartplotter	Yes
NMEA 2000	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX7
Operating Voltage	12V DC
Sonar	Yes (built-in)
Cartography	C-MAP, Navionics
Mounting Type	Bracket or Flush Mount
Screen Size	7-inch, 9-inch
Screen Resolution	800 x 480 pixels
