Simrad GO XSE Installation Manual

Technical specifications
Ú
Note: The most up-to-date specifications list is available at:
www.simrad-yachting.com
Mechanical/Environmental
Casing PC/ABS
Operating temp -15°C to +55°C (+5°F to +131°F)
Water ingress IPX6 and 7
Weight (excluding mounting
hardware)
• .526 kg (1.16 lbs) - GO5 XSE
• .907 kg (2 lbs) - GO7 XSE
• 1.315 kg (2.9 lbs) - GO9 XSE
Screen brightness 1200 nits
Screen resolution 480 x 800 (H x W)
Viewing angle in degrees
(typical value at contrast ratio =
10)
L/R: 70, top: 50, bottom: 60
Dimensions (overall) See dimension drawings
Electrical
Operating voltage 10 - 17 V DC
Current draw at 13.6 V (sonar off,
max B/L)
1 A
Low power standby mode yes
Protection reverse polarity and temporary
over-voltage to 36 V
Alarm output current 1 A max
Processor iMX61 single core
Conformity CE, C-Tick
8
Technical specifications | GO XSE Installation Manual
73
