20mm
(0.78in)
17mm
(0.67in)
110mm (4.3in)
110mm (4.3in)
IS12 Combi
42
E04052
5.3 Dimensions
5.4 Specification
Supply Voltage 12v (9-16v) DC
Current Consumption Light Off - 40mA Light On - 60mA
Transducer Frequency 200kHz
Sounding Range 0.6 - 100m (2 - 327ft)
Max Depth Resolution 0.1m / 1ft
Speed Range 0-60 Kts, mph, Kmh
Max Speed Resolution 0.1 Kts, mph, Kmh
Sea Temperature 0-37ºC (32-99ºF)
Max units per system 32
Ambient Temp Range -10ºC to +55ºC (14ºF to 140ºF)
5.5 Service & Warranty
Your equipment should seldom need servicing, although it will
benefit from an application of silicone or Teflon grease to the
contacts each season. The transducer should be removed and
cleaned of fouling regularly, and we recommend it is removed
and replaced with the bung supplied if the boat is to be laid up.
The unit is guaranteed for 2 years from date of retail sale. If it is
necessary to have the unit repaired, return it carriage prepaid to
the agent in the country of purchase with a copy of the receipted
invoice showing the date of purchase. Where possible, return
all the components unless you are certain that you have located
the source of the fault. If the original box is not available, ensure
that it is well cushioned in packing; the rigours of freight han-
dling can be very different from the loads encountered in the
marine environment for which the unit is designed.
For Worldwide Warranty details, please refer to the Warranty
Card supplied with this unit.
75mm (3.0in)
50mm (2.0in)
89mm (3.5in)
125mm (4.9in)
75mm (3.0in)
50mm (2.0in)
89mm (3.5in)
