1.2 IS12 Network System
The IS12 system is built around a high speed bus networking
system that allows instruments to be easily interconnected and
share data.
All units are interconnected and powered using a standard sin-
gle cable (Fig 1.2) -
Instruction Manual
7
E04052
Additional instruments can be added to the system to act as
repeaters, for example at the chart table of a sailboat or the fly-
bridge of a powerboat. Thus, as shown in the example above,
the Mega and Data Repeater instruments repeat the informa-
tion from the main instruments.
Fig 1.2 - IS12 Network System
COMBI
CONTROLLER
ALARM
DATA COMPASS
MEGAMEGA WIND
WIND Tx
COMPASS Tx
