Simrad IS80 Heading Repeater HR80 User Manual

10 | Installation
Installation setup
SimNet, NMEA0183 and Demo mode are selectable
inputs on the HR80. After installation, the system must
be configured to read the preferred input signal before
the instrument is ready for use.
The Installation
setup is accessed
as shown in the
illustration.
As an example the illustration below shows the LED
reading when the input type is changed from SimNet to
Demo.
Refer also to the Operation flow chart in the Operation
section.
The compas card position will change accordingly as
shown in the table.
SIGNAL INPUT LCD COMPASS CARD
SimNet
5 1
NMEA183
Demo
Local SimNet reset
Under the SimNet input, select the L.res window and
press both keys to save the local reset of SimNet.
A. 1 A.2
SELECT
MODE
SETUP
SELECT
+
1 s
3 s
5 1
0 183
- MODE 1
- MODE 2
- INPUT
SIGNAL
- RESET
MAIN
MODES
INSTALLATION
SETUP
MODE
SETUP
SELECT
10 s
+
MODE
SETUP
SELECT
+
5 s
- MODE 1
- MODE 2
- INPUT
SIGNAL
- RESET
MAIN
MODES
INSTALLATION
SETUP
MODE
SETUP
SELECT
10 s
+
MODE
SETUP
SELECT
+
5 s
