Installation | 7
2 Installation
Location of the unit
The HR80 should be mounted with special regard to the
unit’s environmental protection, temperature range and
cable length. Refer to the Specifications section.
Avoid mounting the unit where it is easily exposed to
sunlight, as this may unintendedly overheat the unit.
Panel mounting
The mounting surface must be at and even to within
0.5 mm.
Drill 4 mounting holes and make a panel cut-out 1
according to the drilling template included in the
package
Use the supplied self tapping screws to secure the 2
unit to the panel
Apply the front corners3
Do not over-tighten the screws!
