Specications | 23
6 Specications
Technical specications
Power supply ....................................12/24V DC (+30%, -10%)
Power consumption .......................................................< 5W
SimNet network load ...................................................... 1 NL
Input signals:
NMEA2000/SimNet ....................................... 1 can channel
NMEA0183: .......................... 1 optoisolated RS485 channel
Input mode selection: ..........................NMEA2000/SimNet,
NMEA0183,
Demo mode
NMEA0183 to SimNet converter: ................When NMEA0183
is selected
Weight: ....................................................... 0.55 kg (1.21 lb)
Material: .......................................................ASA/PC Luran S
Color: .......................................................................... Black
Display:
Dial: ...................................................................0 - 359°
Marking: ....................................................................10°
Illumination:.................................... Adjustable in 10 steps
Digital display: ................................. Four 7-segment LEDs
Environmental protection:
Front ....................................................................... IP66
Back: ...................................................................... IP20
Safe distance to compass:
Steering compass .................................... 0.40 m (1.32 ft.)
Stand-by/Emergency distance ................... 0.20 m (0.66 ft.)
Temperature:
Operating: ............................. -15 to +70°C (+5 to +158°F)
Storage: ...............................-40 to +80°C (-40 to +176°F)
Climate
Max 95% RH: ................................... Max 30 days per year
Max 85% RH: ........................................... Remaining days
Max 75% RH: ......................................... Average per year
