Introduction | 5
1 Introduction
General information
The HR80 Instrument presents you with heading
information on a combined analog and digital display.
Adjustable backlight for night operation is provided
as well as adjustable intensity on the LED displays for
operation in sunshine.
Instrument layout
The HR80 display includes an LED bargraph, compass
card and LED display. Modes of operation and signal
input are indicated by monitor diodes.
The instrument is
operated by 2 keys.
These are used to switch
between display modes,
to set parameter values
and to adjust background
illumination.
