NMEA 0183 supported sentences
TX / RX - GPS
Receive GGA GLL GSA GSV VTG ZDA
Transmit GGA GLL GSA GSV VTG ZDA GLC
TX / RX - Navigation
Receive RMC
Transmit AAM APB BOD BWC BWR
Receive
Transmit RMC RMB XTE XDR
TX / RX - Sonar
Receive DBT DPT MTW VLW VHM
Transmit DBT DPT MTW VLW VHM
TX / RX - Compass
Receive HDG HDT HDM
Transmit HDG
TX / RX - Wind
Receive MWV MWD
Transmit MWV MWD
TX / RX - AIS / DSC
Receive DSC DSE VDM
Ú
Note: AIS sentences are not bridged to or from NMEA 2000.
TX / RX - MARPA
Transmit TLL TTM
Ú
Note: These are only output sentences.
48
Supported data | NSS evo3 Installation Manual
