Simrad NSS evo3 Installation Manual

Contents
8 Check the contents
9 Overview
9
Front controls
10 Rear connections
10 Card reader
11 Installation
11 Mounting location
12 Bracket mounting
12 Flush mounting
13 Bezel Fitment and Removal
13 Transducer mounting location
15 Wiring
15 Guidelines
15 Power connection
15 Power Control connection
17 Power Control master/slave bus
18 External alarm
18 Connect an external monitor
19 NMEA 2000 backbone
20 NMEA 0183 device connection
21 CZone connection to NMEA 2000
21 Transducer connection
22 Ethernet connector
23 Video in
24 Software Setup
24 First time startup
24 Configuring the WheelKey
24 Time and Date
24 Power Control
24 Data source selection
26 Device list
26 SimNet Groups
26 Diagnostics
27 Damping
27 Calibration
27 External Alarm Setup
27 Echosounder setup
30 StructureScan
30 Radar setup
33 Video In configuration
33 Autopilot setup
33 Fuel setup
35 CZone setup
36 Wireless setup
39 NMEA 0183 setup
41 NMEA 2000 setup
41 Ethernet setup
43 Mercury®
43 Suzuki Marine®
43 Software updates and data backup
45 Accessories
45 NSS evo3 accessories
6
Contents | NSS evo3 Installation Manual

Simrad NSS evo3 Specifications

General

Touchscreen	Yes
NMEA 0183 Connectivity	Yes
Operating System	Linux-based
Chartplotter	Yes
Radar Support	Yes
Waterproof Rating	IPX7
Operating Temperature	-15°C to +55°C
Display Size	9, 12, 16 inches
Screen Type	LCD
GPS	10 Hz built-in GPS receiver
Networking	Ethernet, Wi-Fi, Bluetooth
Sonar	CHIRP, StructureScan
Power Supply	12V DC
Video Input	2
Card Slots	2 x MicroSD
Processor	Quad-core processor
RAM	1GB
Internal Storage	8GB
Resolution	1280 x 800 (12")
