Simrad NSS evo3 Installation Manual

Check the contents
1
3
2
10
4
5
8
7
ENGLISH
Installa
t
ion Manua
l
E
NGLI
S
H
I
n
stalla
t
ion Manual
E
NGLISH
I
n
stalla
t
ion Manual
ENGLISH
Installation M
anua
l
6
12
13
14
11
9
1 Display unit
2 Sun cover
3 Bezel trim
4 Power cable
5 Self tapping pozi screws, 4Gx1/2” (x4 for 7", x8 for 9"/12", & x12 for 16" units)
6 Dust caps, different sizes for NMEA 2000 (x1), Ethernet (x1 for 7"/9", x2 for 12"/16")
and Sonar (x2) connectors
7 Dust cap for HDMI connector (12" and 16" only)
8 Dust cap for Video/NMEA 0183 connector
9 Dust cap for USB (16" only)
10 Document pack
11 Foam gasket (self adhesive)
12 U-bracket
13 Bracket knobs
14 Self tapping pozi screws for bracket, 14G x 1”
1
8
Check the contents | NSS evo3 Installation Manual

Simrad NSS evo3 Specifications

General

Touchscreen	Yes
NMEA 0183 Connectivity	Yes
Operating System	Linux-based
Chartplotter	Yes
Radar Support	Yes
Waterproof Rating	IPX7
Operating Temperature	-15°C to +55°C
Display Size	9, 12, 16 inches
Screen Type	LCD
GPS	10 Hz built-in GPS receiver
Networking	Ethernet, Wi-Fi, Bluetooth
Sonar	CHIRP, StructureScan
Power Supply	12V DC
Video Input	2
Card Slots	2 x MicroSD
Processor	Quad-core processor
RAM	1GB
Internal Storage	8GB
Resolution	1280 x 800 (12")
