may be inaccurate or not available at all if the wrong transducer is selected. Transducer

temperature sensors are one of two impedances - 5k or 10k. Where both options are given

for the same model transducer, refer to paperwork supplied with transducer to determine

impedance.

ForwardScan installation

Available when the ForwardScan feature is turned on. For installation and setup information,

refer to the separate ForwardScan documentation.

StructureScan

This feature is automatically enabled when a TotalScan transducer is plugged in before the

unit has been powered on.

You should set the Structure depth offset for the structure transducer. This settings is in

the Echosounder Settings dialog.

Radar setup

Use the Radar Installation dialog to setup the radar.

Note: The installation can vary depending on the radar. Follow the installation and setup

instructions supplied with the radar.

Radar source

In a system with more than one radar, the correct device to configure can be selected from

this menu.

Note: Radars that support dual radar mode are represented twice in the source list, with

an A and B suffix.

Radar status

Scanner type

Identifies the model of scanner connected to the network.

Software Setup | NSS evo3 Installation Manual
