Simrad Autopilot Compass
32 20220653 / Rev. C
Colour code in brackets ( ) is for
moulded type connector only.
Removable connector
Solder type
Moulded connector
J1
NMEA
J2
ROBNET
J3
EXT.COMP
VIN-
WHITE (BROWN)
VIN+
RX+
RX-
6543
2
1
112234
NMEA PCB
MICRO-CONTROLLER
TX-
TX+
GREY (YELLOW)
BROWN (WHITE)
PINK (GREY)
G
R
E
E
N
(
P
I
N
K
)
Y
EL
L
O
W
(
G
REE
N
)
Figure 5-12 RFC35N as RFC300 substitution
Calibration
Automatic calibration is activated from AP300 “Seatrial” menu
and RFC35N needs only 1¼ turn to complete the calibration.
(RFC300 needs 3 times through North.)
Calibration data and any heading offset is stored in the compass
and will not be deleted
by a “Master reset” in the AP300.
