Simrad RC25 - Calibration

Instruction Manual
20220653 / Rev. C 35
J1
NMEA
J2
ROBNET
J3
EXT.COMP
VIN-
WHITE (VIN+)
RX+
RX-
6543
2
1
11223
4
NMEA/RATE PCB
SIN PCB
B
L
A
CK
G
R
E
E
N
+
R
E
D
V
I
O
L
E
T
Y
E
L
L
O
W
Cable 22083661
BROWN (TX-)
BLUE (TX+)
0,5 m
Original RFC250 cable
(Part no. 20183554)
RFC35NS
Figure 5-16 RFC35NS as RFC250 substitution; internal connections
Note ! The optional SIN PCB can not be used with a standard RFC35 -
only with RFC35N (or RFC35R).
Calibration
As for RC37 described in previous section 5.5.
