Simrad RS87 User Manual

Instruction Manual
73
E04819 Issue 1.0
7.2.10 Summary of connections
Summary of the RS86/RS87 connections (Fig 7.15):
STANDARD CONNECTIONS EXPANSION BOARD
Terminal
Number
1
2
3
4
5
6
7
8
Wire
Color
Brown
Green
Red
White
Blue
Yellow
Orange
Black
Terminal
Number
1
2
3
Wire
Color
Black
Red
White
Terminal
Number
1
2
3
4
Wire
Reference
Aft +
Aft -
Fore +
Fore -
Terminal
Number
1
2
Wire
Color
Red
Blue
Terminal
Number
1
2
Wire
Reference
Line Out +
Line Out -
Station 1
Terminal
Number
1
2
3
4
5
6
7
8
Wire
Color
Brown
Green
Red
White
Blue
Yellow
Orange
Black
Station 2
Terminal
Number
1
2
3
4
5
6
7
8
Wire
Color
Brown
Green
Red
White
Blue
Yellow
Orange
Black
Station 3
Terminal
Number
1
2
3
4
5
6
7
8
Wire
Color
Brown
Green
Red
White
Blue
Yellow
Orange
Black
Station 4 Fog/Hailers
Terminal
Number
1
2
3
4
Wire
Reference
Common Out -
Data Out +
iDSC -
iDSC +
NMEA/iDSC
Intercoms
(Int1/Int2)
Horn Key Aux AF
Terminal
Number
+
-
Wire
Reference
Red (12V in)
Black (0V)
PWR
STANDARD CONNECTIONS
EXPANSION BOARD CONNECTIONS
Fig 7.15 - Transceiver unit connections summary
