Appendix A –– Programming Address Table
- Programming -
Address Description Section Default Current Alternate Use / Notes
RFC-1 Programming Address Table page A.1
0000 Channel 00: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 80: action sequence
0001 Channel 00: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 80: month
0002 Channel 00: full scale and decimal point 6.3.3 2 ____ Date/time 80: date - value 1
0003 Channel 00: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 80: date - value 2
0004 Channel 01: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 80: hour - value 1
0005 Channel 01: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 80: hour - value 2
0006 Channel 01: full scale and decimal point 6.3.3 2 ____ Date/time 80: minute - value 1
0007 Channel 01: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 80: minute - value 2
0008 Channel 02: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 79: action sequence
0009 Channel 02: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 79: month
0010 Channel 02: full scale and decimal point 6.3.3 2 ____ Date/time 79: date - value 1
0011 Channel 02: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 79: date - value 2
0012 Channel 03: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 79: hour - value 1
0013 Channel 03: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 79: hour - value 2
0014 Channel 03: full scale and decimal point 6.3.3 2 ____ Date/time 79: minute - value 1
0015 Channel 03: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 79: minute - value 2
0016 Channel 04: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 78: action sequence
0017 Channel 04: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 78: month
0018 Channel 04: full scale and decimal point 6.3.3 2 ____ Date/time 78: date - value 1
0019 Channel 04: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 78: date - value 2
0020 Channel 05: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 78: hour - value 1
0021 Channel 05: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 78: hour - value 2
0022 Channel 05: full scale and decimal point 6.3.3 2 ____ Date/time 78: minute - value 1
0023 Channel 05: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 78: minute - value 2
0024 Channel 06: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 77: action sequence
0025 Channel 06: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 77: month
0026 Channel 06: full scale and decimal point 6.3.3 2 ____ Date/time 77: date - value 1
0027 Channel 06: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 77: date - value 2
0028 Channel 07: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 77: hour - value 1
0029 Channel 07: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 77: hour - value 2
0030 Channel 07: full scale and decimal point 6.3.3 2 ____ Date/time 77: minute - value 1
0031 Channel 07: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 77: minute - value 2
0032 Channel 08: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 76: action sequence
0033 Channel 08: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 76: month
0034 Channel 08: full scale and decimal point 6.3.3 2 ____ Date/time 76: date - value 1
0035 Channel 08: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 76: date - value 2
0036 Channel 09: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 76: hour - value 1
0037 Channel 09: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 76: hour - value 2
0038 Channel 09: full scale and decimal point 6.3.3 2 ____ Date/time 76: minute - value 1
0039 Channel 09: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 76: minute - value 2
0040 Channel 10: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 75: action sequence
0041 Channel 10: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 75: month
0042 Channel 10: full scale and decimal point 6.3.3 2 ____ Date/time 75: date - value 1
0043 Channel 10: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 75: date - value 2
0044 Channel 11: telemetry units or status format - value 1 6.3.2 0 ____ Date/time 75: hour - value 1
0045 Channel 11: telemetry units or status format - value 2 6.3.2 3 ____ Date/time 75: hour - value 2
0046 Channel 11: full scale and decimal point 6.3.3 2 ____ Date/time 75: minute - value 1
0047 Channel 11: linear/log/indirect and auto relay
6.3.4 0 ____ Date/time 75: minute - value 2
