Sine Systems RFC-1/B User Manual

RFC-1 Advanced Operation page 6.17
6.5.3 Control Relay Operation
The RFC-1 can operate any of the control relays as a step in an action sequence. Select an instruction from the list
below and program V1 and V2 in the action sequence to activate the associated control relay. Control relays are
momentary activation only. There is no need to execute an on instruction followed by a corresponding off instruction.
V1-V2
Relay Activated
V1-V2
Relay Activated
V1-V2
Relay Activated
V1-V2
Relay Activated
0-0
Channel 00 on
1-0
Channel 16 on
2-0
Channel 32 on
3-0
Channel 48 on
0-1
Channel 01 on
1-1
Channel 17 on
2-1
Channel 33 on
3-1
Channel 49 on
0-2
Channel 02 on
1-2
Channel 18 on
2-2
Channel 34 on
3-2
Channel 50 on
0-3
Channel 03 on
1-3
Channel 19 on
2-3
Channel 35 on
3-3
Channel 51 on
0-4
Channel 04 on
1-4
Channel 20 on
2-4
Channel 36 on
3-4
Channel 52 on
0-5
Channel 05 on
1-5
Channel 21 on
2-5
Channel 37 on
3-5
Channel 53 on
0-6
Channel 06 on
1-6
Channel 22 on
2-6
Channel 38 on
3-6
Channel 54 on
0-7
Channel 07 on
1-7
Channel 23 on
2-7
Channel 39 on
3-7
Channel 55 on
0-8
Channel 08 on
1-8
Channel 24 on
2-8
Channel 40 on
3-8
Channel 56 on
0-9
Channel 09 on
1-9
Channel 25 on
2-9
Channel 41 on
3-9
Channel 57 on
0-10
Channel 10 on
1-10
Channel 26 on
2-10
Channel 42 on
3-10
Channel 58 on
0-11
Channel 11 on
1-11
Channel 27 on
2-11
Channel 43 on
3-11
Channel 59 on
0-12
Channel 12 on
1-12
Channel 28 on
2-12
Channel 44 on
3-12
Channel 60 on
0-13
Channel 13 on
1-13
Channel 29 on
2-13
Channel 45 on
3-13
Channel 61 on
0-14
Channel 14 on
1-14
Channel 30 on
2-14
Channel 46 on
3-14
Channel 62 on
0-15
Channel 15 on
1-15
Channel 31 on
2-15
Channel 47 on
3-15
Channel 63 on
V1-V2
Relay Activated
V1-V2
Relay Activated
V1-V2
Relay Activated
V1-V2
Relay Activated
4-0
Channel 00 off
5-0
Channel 16 off
6-0
Channel 32 off
7-0
Channel 48 off
4-1
Channel 01 off
5-1
Channel 17 off
6-1
Channel 33 off
7-1
Channel 49 off
4-2
Channel 02 off
5-2
Channel 18 off
6-2
Channel 34 off
7-2
Channel 50 off
4-3
Channel 03 off
5-3
Channel 19 off
6-3
Channel 35 off
7-3
Channel 51 off
4-4
Channel 04 off
5-4
Channel 20 off
6-4
Channel 36 off
7-4
Channel 52 off
4-5
Channel 05 off
5-5
Channel 21 off
6-5
Channel 37 off
7-5
Channel 53 off
4-6
Channel 06 off
5-6
Channel 22 off
6-6
Channel 38 off
7-6
Channel 54 off
4-7
Channel 07 off
5-7
Channel 23 off
6-7
Channel 39 off
7-7
Channel 55 off
4-8
Channel 08 off
5-8
Channel 24 off
6-8
Channel 40 off
7-8
Channel 56 off
4-9
Channel 09 off
5-9
Channel 25 off
6-9
Channel 41 off
7-9
Channel 57 off
4-10
Channel 10 off
5-10
Channel 26 off
6-10
Channel 42 off
7-10
Channel 58 off
4-11
Channel 11 off
5-11
Channel 27 off
6-11
Channel 43 off
7-11
Channel 59 off
4-12
Channel 12 off
5-12
Channel 28 off
6-12
Channel 44 off
7-12
Channel 60 off
4-13
Channel 13 off
5-13
Channel 29 off
6-13
Channel 45 off
7-13
Channel 61 off
4-14
Channel 14 off
5-14
Channel 30 off
6-14
Channel 46 off
7-14
Channel 62 off
4-15
Channel 15 off
5-15
Channel 31 off
6-15
Channel 47 off
7-15
Channel 63 off
Control relay activations are always momentary. The relay operating time controls the minimum length of time that a
control relay is engaged when activated. When a relay is activated manually, the relay will be engaged as long as the
control key is pressed. This setting is stored at memory address 1006 in the address table.
V1
Minimum control relay operate time
V1
Minimum control relay operate time
0
0.3 seconds
8
2.7 seconds
1
0.6 seconds (default setting)
9
3.0 seconds
2
0.9 seconds
10
3.3 seconds
3
1.2 seconds
11
3.6 seconds
4
1.5 seconds
12
3.9 seconds
5
1.8 seconds
13
4.2 seconds
6
2.1 seconds
14
4.5 seconds
7
2.4 seconds
15
4.8 seconds
