14
Press the " " button to lock the Function and
Selection buttons. Press the " " button again
to unlock. Lock buttons to prevent stitch settings
from accidentally being changed.
Attention: While the key lock button is locked
the Function and Selection buttons cannot be
operated.
Key lock button
FUNC
FUNC selection button
The LCD screen will be set at direct mode A when
you turn on the machine. By pressing the " "
button, the LED light will turn on. LCD screen
enters the pattern group screen automatically.
Press the numbered button corresponding to the
group of stitches. For example : Press FUNC, then
2 for group B. Then press the 2 digit pattern
number from group B on the stitch chart.
Direct mode stitch selection (Group 1-A)-
Select pattern from the numbered buttons or
" ", and then 1 to reenter direct selection.
Utility and decorative pattern mode (Group
2-B)- Press " ", then 2, and then pattern
number by using the numbered buttons.
Quilt pattern mode (Group 3-C)- Press " ",
then 3, and then pattern number by using
the numbered buttons.
Decorative pattern mode (Group 4-D)- Press
" ", then 4, and then pattern number by
using the numbered buttons.
Block letter mode - Press " ", then 5, and
then pattern number by using the numbered
buttons.
Script letter mode - Press " ", then 6, and
then pattern number by using the numbered
buttons.
FUNC
Put the empty bobbin on the bobbin winder shaft.
Push the bobbin winder switch to the left.
Press the " " button to wind the bobbin.
The LED light will be on while the bobbin is
winding.
Bobbin can wind in any operation mode.
Bobbin winding button
FUNC
FUNCTION BUTTONS
INSTRUCTIONS
