Singer QUANTUM L-500 - Upper Threading

UPPER THREADING
Note: It is important to thread the machine correctly. Improper threading could result in
several sewing problems.
6
7
8
9
10
2
1
3
4
5
27
1
2
Before threading the machine, raise the needle
to its highest point and raise the presser foot
to release the tension discs.
1. Slide the spool of thread onto the spool pin
so the thread unwinds clockwise from the
thread spool. Then position the spool cap on
the spool pin to secure the spool of thread.
2. Place thread in the thread guide above the
spool of thread.
Threading the upper thread
GETTING READY
