Attention: Do not move the sewing machine
while the extension table is attached, otherwise
damage and/or injury may occur.
47
1. Take out the extension table and seven
extension table feet from the packaging.
Place one of the feet under one of the holes in
the and tighten the top screw
with the .
Repeat for the remaining feet.
Remove the screws from each of the feet with
the large slotted screwdriver.
extension table
large slotted screwdriver
2
3. Keeping the extension table level, slide it up
against the sewing machine.
To adjust the height of the extension table,
turn the rubber knobs under each of the feet to
the proper height.
1
2. Pull the sewing table and accessory box off
by sliding it to the left.
Installing the extension table
3
SEWING BASICS
USEFUL FUNCTIONS
Note: The extension table is an optional
accessory, not included.
