Singer QUANTUM L-500 - Inserting a Centered Zipper

1. Baste the zipper opening on the garment.
2. Press open the seam allowance. Place the
zipper face down on the seam allowance with
the teeth against the seam line. Baste the
zipper tape.
3. Attach the zipper foot. Attach the left side of
the presser foot pin to the presser foot holder
when sewing the right side of the zipper.
4. Attach the right side of the presser foot pin to
the presser foot holder when sewing the left
side of the zipper.
5. Stitch left side of the zipper from bottom to top.
6. Stitch across the lower end and right side of
zipper. Remove the basting stitches and press.
Inserting a centered zipper
Attention: Zipper foot should be used for
sewing with the centered needle position
straight stitch only. It is possible that the
needle could hit the presser foot and break
when sewing other patterns.
ZIPPER INSERTION
3mm
(1/8")
1 2
6
4
5
RB
3
55
4.0
1.5~3.0
STITCHES
