61 23 488 D 3474
20 D 3474.208.01.06.02 04.2010
Workspaces Sirona Dental Systems GmbH
"Detail" workspace Operator's Manual GALAXIS
Views
6.7 "Detail" workspace
Scope
This workspace is not available for GALAXIS in connection with model versi-
on GAX5.
Explanation The "Detail" workspace shows an enlarged view of the area inside the exami-
nation window.
The voxels are reconstructed and redisplayed with an edge length of 150 µm.
See the section "Creating a detail volume [ ➙ 43]".
A Ceph lateral
B 3D view [ ➙ 23]
C Axial plane
D Coronal plane
5
