Sirona Dental Systems GmbH Functions
Operator's Manual GALAXIS Zoom function
båÖäáëÜ
empty
Resetting the
"Superimpose"
function
➢ Press the
"Single"
button.
ª One axial slice will then be displayed.
empty
Navigating through axial slices
To navigate through the axial slices, proceed as follows:
➢ Press the
"Navigate into the volume by one slice."
button.
ª The current view then moves in one slice.
1. Press the
"Navigate out of the volume by one slice."
button.
ª The current view then moves one slice out of the volume each time
you press the button.
2. Confirm your setting with the
"OK"
button.
8.11 Zoom function
Explanation Using the
"Zoom in"
and
"Zoom out"
functions, you can increase or decrease
the size of any view.
Enlarging ➢ Roll the mouse scroll wheel forward (up).
or
➢ Click the
"Zoom in"
button.
or
➢ Click on the
"Zoom in"
menu option on the
"View"
/
"Zoom"
menu bar.
Reducing ➢ Roll the mouse scroll wheel back (down).
or
➢ Click the
"Zoom out"
button.
or
➢ Click on the
"Zoom out"
menu option on the
"View"
/
"Zoom"
menu bar.
8.12 Transfer function
Explanation The display of the medium shades of gray can be changed via a gamma cor-
rection in the transfer function
Command ➢ Select the
"Transfer function…"
menu option on the
"View"
menu bar.
ª The
"Transfer function"
dialog box then appears.
Operation 1. Move the
"Gamma"
slider as required.
2. Confirm your setting with the “
"OK"
” button.
