Sirona Dental Systems GmbH Functions
Operator's Manual GALAXIS Creating a detail volume
båÖäáëÜ
➢ Click on the
"Navigate out of the volume by one slice."
button.
ª The current view then moves one slice out of the volume each time you
press the button.
Accepting settings ➢ Press the
"OK"
button.
ª The
"New Ceph"
dialog box is then closed and a Ceph view is recon-
structed.
8.16 Creating a detail volume
Scope
This function is not available for GALAXIS in connection with model version
GAX5.
Explanation If a detail reconstruction is required, one can be produced with the
"Close-Up"
function.
The
"Close-Up"
function creates a detail reconstruction from the region dis-
played inside the examination window.
The region inside the examination window is reconstructed with a voxel size
of 150 µm.
Command
➢ Click the
"Close-Up"
button.
or
➢ Use the
"Analysis"
menu bar to select the
"Close-Up"
menu option.
ª The
"Close-Up"
dialog box appears.
Configuration The examination window from the panoramic view is displayed in 3 planes
(axial, coronal and sagittal).
This is the region of the detail reconstruction to be created.
If the displayed region does not correspond to the desired region, you must
close the dialog box and reposition the examination window.
Operation
empty
Assigning names
A name can be assigned to the detail reconstruction in the
"Name"
input field.
This name will then be displayed on the tab.
If no name is assigned, automatic incrementation will take place.
empty
Accepting settings
➢ Press the
"OK"
button.
ª The
"Close-Up"
dialog box is then closed and a detail reconstruction is
produced.
